SuperHitch Magnum™ & SuperTruss® Receiver Extension
An unbeatable twin beam SuperTruss receiver extension system creates the highest rating in the industry!










The Torklift Difference

  Torklift Reese*
Hitch Capacity with 48" Extension 600lbs Tongue Wt 6,000lbs Pull Wt 4,000lbs Pull Wt
Hitch Capacity with 48" Extension and Weight Distribution 1,200lbs Tongue Wt 12,000lbs Pull Wt 6,000lbs Pull Wt
Lateral support safety chain system and plug bracket included in cost YES NO
Lateral support safety chains not available, plug brackets extra
No drill applications YES NO
Hitch utilizes industry standard 2" x 2" ballmounts without adapter YES
 		NO
Uses 2.5" x 2.5" receiver
Hitch utilizes Hardened / Reinforced hitch pin holes YES NO
*Reese Titan/ Tow Beast are registered trademarks of Cequent Towing


YEAR MAKE/
MODEL		 BED
LENGTH		 PART # NOTES HOLES TO DRILL
FORD
99-10 F250 / F350 SHORT or
LONG BED

  NONE
08-10 F450 FACTORY
8' F350
BED		   NONE
CHEVROLET
01-09 2500 / 3500 HD Classic & New Body
 LONG BED
   NONE
07-09 2500 / 3500 HD New Body SHORT
BED
   NONE
2007 KODIAK CAB & CHASSIS
   NONE
DODGE / STERLING
07-09 3500 / 4500 / 5500
 CAB & CHASSIS
   NONE
03-09
2500 HD
3500 HD

SHORT
or
LONG BED
WITH
FACTORY
HITCH
(details)

   NONE
03-09
2500 HD
3500 HD

SHORT
or
LONG BED
WITHOUT
FACTORY
HITCH
(details)

COMING SOON

   NONE


Lifetime Guarantee

SuperHitch frame mounted receiver rated up to 20,000 lbs. with weight distribution (17,000 weight carrying) in either the upper or lower receivers. (When used without SuperTruss extension.)

Extension towing capacity up to 12,000 lbs. with 48” SuperTruss receiver extension.*

SuperTruss Extensions available in 7 different lengths from 21” to 48”. (Sold Separately)

Designed for up to 12’ campers.

Industry Exclusive, Patented Lateral support safety chain assemblies.

Both the SuperHitch Magnum frame mount receiver and the SuperTruss receiver extensions use Industry standard 2” x 2” ballmounts.

Eliminates the need for two ball mounts **

Pre-drilled for TorkLift Camper Tie Downs

*12,000 lb. pulling capacity, 1,200 tongue wt. achieved only when used with weight distribution type system. See Dealer for details, Weight carring capacity on 48” extension, 6,000 lb. pull, 600 lb. tongue wt. Consult your vehicle owners manual for specific towing capacity. Your truck and trailer weight cannot exceed your vechile manufacturers towing, cargo, or GCVWR.

**(Camper on, camper off, hight variance) obtained by using the ball mount in either upper or lower SuperHitch receiver.
