Installation Disclaimer: This blog is intended as a general reference only. It may not include every step, tool, torque specification, or vehicle-specific detail needed for your installation. Always refer to the official installation instructions included with your product for the complete procedure, required tools, torque values, safety information, and fitment details.
Installing rear tie downs for your Torklift SuperHitch is a straightforward process that you can complete with basic tools. These tie downs work in conjunction with your SuperHitch to provide secure anchor points for your truck camper.
What You'll Need
Before beginning the installation, make sure you have the necessary tools on hand. You'll need a wrench or socket set capable of tightening nuts to 90 ft-lbs, which means a torque wrench is recommended for proper installation.
Compatible Part Numbers
This installation guide applies to the following Torklift part numbers:
Installation Steps
Step 1: Remove the Existing Nuts
Start by locating the two nuts facing the front of the truck. Loosen and completely remove these nuts. Set them aside in a safe place as you'll be reusing them.
Step 2: Position the Tie Down
Slide the tie down into the cross tube. Align the holes in the tie down with the bolts on your SuperHitch. This step is simple once you have the component properly oriented.
Step 3: Secure the Tie Down
Put the nuts back onto the bolts and tighten them down to 90 ft-lbs. Proper torque is important for ensuring the tie downs remain secure under load.
Step 4: Repeat on the Other Side
The installation process is identical on both sides of your vehicle. Before installing, make sure you identify which piece is designated for the driver side and which is for the passenger side. Installing the correct piece on each side ensures proper fit and function.
Step 5: Install the Insert
Once both tie downs are secured, slide the insert into position and secure it with a quarter-inch pin. This insert will be ready to use whenever you need to tie down your camper.
Using Your Tie Downs
When you're ready to secure your truck camper, simply ensure the insert is in place and secured with the quarter-inch pin. The tie downs will provide reliable anchor points for your camper tie down system.
Frequently Asked Questions
What torque specification should I use for the tie down nuts?
Tighten the nuts to 90 ft-lbs for proper installation.
Do I need different parts for the driver and passenger sides?
Yes, make sure to identify which pieces are designated for the driver and passenger sides before installing them.
Which Torklift part numbers does this installation apply to?
This installation process applies to part numbers R3504, R3505, R3507, R3508, R3509, and R3510.
How difficult is this installation?
This is a straightforward installation. The process is the same on both sides, making it easy to complete once you've done one side.
What size pin is needed to secure the insert?
You'll need a quarter-inch pin to secure the insert when you're ready to use the tie downs.
