SMARTSTEP® GlowStep Step Specifications
|
6" Deep GlowSteps with 6" x 20" Step Dimensions
| ||||||||
|---|---|---|---|---|---|---|---|---|
| Glow Step | Mounting Bracket Dimensions | Entry Height | Max Weight | |||||
| Add A Step Part Number: A7501 | - | - | - | |||||
| 3 Step Part Number: A7503 |
21.5" wide x 8.56" deep | 23.5" to 30.5" | 350lbs† | |||||
| 4 Step Part Number: A7504 |
21.5" wide x 8.56" deep | 31" to 38" | 350lbs† | |||||
| 5 Step Part Number: A7505 |
21.5" wide x 8.56" deep | 38.5" to 46" | 300lbs† | |||||
| 6 Step Part Number: A7506 |
21.5" wide x 8.56" deep | 46.5" to 54" | 300lbs† | |||||
|
8" Deep GlowSteps with 8" x 20" Step Dimensions
| ||||||||
| Glow Step | Mounting Bracket Dimensions | Entry Height | Max Weight | |||||
| Add A Step Part Number: A7801 |
- | - | - | |||||
| 2 Step Part Number: A7802 |
21.5" wide x 8.56" deep | 16" to 23" | 375lbs†† | |||||
| 3 Step Part Number: A7803 |
21.5" wide x 8.56" deep | 23.5" to 30.5" | 375lbs†† | |||||
| 4 Step Part Number: A7804 |
21.5" wide x 8.56" deep | 31" to 38" | 375lbs†† | 5 Step Part Number: A7805 |
21.5" wide x 8.56" deep | 38.5" to 46" | 325lbs†† | |
| 6 Step Part Number: A7806 |
21.5" wide x 8.56" deep | 46.5" to 54" | 325lbs†† | |||||
| Footnotes: | ||||||||
| †With use of Torklift GlowGuide. Otherwise 2-4step MAX CAP 325lbs / 5-6 MAX CAP 275lbs | ||||||||
| ††With use of Torklift GlowGuide. Otherwise 2-4step MAX CAP 350lbs / 5-6 MAX CAP 300lbs | ||||||||
| Each 2 - 6 GlowStep Kit includes 1 Universal Surface Mounting Bracket | ||||||||
SMARTSTEP® GlowStep Stow N' Go Step Specifications
|
SMARTSTEP® GlowStep Stow N' Go Step with 20" Wide X 8.56" Mounted Bracket Dimensions
|
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| SMARTSTEP® GlowStep Stow N' Go Step | Drop/Rise | Step Dimensions | Entry Height | Max Weight | |||||
| Add-A-Step Part Number: A7801 |
N/A | 20" wide x 8.56" deep | N/A | N/A | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 3 Step - Black Bracket Part Number: A7833 |
7.5 | 20" wide x 8.56" deep | 23.5" to 30.5" | 375 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 4 Step - Black bracket Part Number: A7834 |
7.5 | 20" wide x 8.56" deep | 31" to 38" | 375 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 5 Step - Black bracket Part Number: A7835 |
7.5 | 20" wide x 8.56" deep | 38.5" to 46" | 325 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 6 Step - Black bracket Part Number: A7836 |
7.5 | 20" wide x 8.56" deep | 46.5" to 54" | 325 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 3 Step - White bracket Part Number: A7843 |
7.5 | 20" wide x 8.56" deep | 23.5" to 30.5" | 375 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 4 Step - White bracket Part Number: A7844 |
7.5 | 20" wide x 8.56" deep | 31" to 38" | 375 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 5 Step - White bracket Part Number: A7845 |
7.5 | 20" wide x 8.56" deep | 38.5" to 46" | 325 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - 6 Step - White bracket Part Number: A7846 |
7.5 | 20" wide x 8.56" deep | 46.5" to 54" | 325 lbs† | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - Upgrade kit for standard GlowSteps - Black bracket only†† Part Number: A7810 |
- | - | - | - | |||||
| SMARTSTEP® GlowStep Stow N' Go Step - Upgrade kit for standard GlowSteps - White bracket only†† Part Number: A7820 |
- | - | - | - | |||||
| Footnotes: | |||||||||
| †With use of Torklift GlowGuide. Otherwise 3-4step MAX CAP 350lbs / 5-6 MAX CAP 300lbs | |||||||||
| ††Bracket only to upgrade standard GlowSteps will fit both 8” deep and 6” deep GlowSteps. Stow N’ Go upgrade kits only work with applications ranging 3-6 steps. Will not work with 2-step GlowStep units. All Terrain Landing Gear not included. | |||||||||
GLOWSTEP REVOLUTION® Specifications
|
GLOWSTEP REVOLUTION® with 8" x 22.25" Steps
|
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Description / Part Number | Width between factory mounting brackets (A) | Height from top of step opening to ground (B) | Height from top of step opening to bottom of stored steps (C) | Weight Capacity | Notes | ||||
|
Add-A-Step (for A8002-A8005) |
27.5" | N/A | N/A | N/A | †, †† | ||||
|
2 Step Part Number: A8002 |
27.5" | 18.5" to 24" | 11.5" to 12.5" | 375lbs |
††† | ||||
|
3 Step Part Number: A8003 |
27.5" | 25.5" to 32" | 13.75" to 14.75" | 375lbs |
††† | ||||
|
4 Step Part Number: A8004 |
27.5" | 32.5" to 40" | 16" to 17" | 375lbs |
††† | ||||
|
5 Step Part Number: A8005 |
27.5" | 39.5" to 48" | 18.25" to 19.25" | 325lbs |
††† | ||||
|
6 Step Part Number: A8006 |
27.5" | 46.5" to 56" | 20.5" to 21.5" | 325lbs |
†††, *,** |
||||
| Add-A-Step (For A8102-A8105) Part Number: A8101B | 25" | N/A | N/A | N/A | †, †† | ||||
| 2 Step Part Number: A8102 |
25-25.5" | 18.5" to 24" | 11.5" to 12.5" | 375lbs | ††† | ||||
|
3 Step Part Number: A8103 |
25-25.5" | 25.5" to 32" | 13.75" to 14.75" | 375lbs | ††† | ||||
|
4 Step Part Number: A8104 |
25-25.5" | 32.5" to 40" | 16" to 17" | 375lbs | ††† | ||||
|
5 Step Part Number: A8105 |
25-25.5" | 39.5" to 48" | 18.25" to 19.25" | 325lbs | ††† | ||||
|
6 Step Part Number: A8106 |
25-25.5" | 46.5" to 56" | 20.5" to 21.5" | 325lbs | †††, *,** | ||||
|
† Do not use Add-A-Step Kit to convert a six-step to a seven-step. †† All Terrain Landing Gear not included. ††† With use of Torklift GlowGuide. Otherwise 2-4step MAX CAP 350lbs / 5-6 MAX CAP 300lbs. * The GLOWSTEP REVOLUTION® is available from two to six steps. The six step is specifically available for side-entry truck campers that have a larger opening to the ground. Most travel trailers, toy haulers and 5th wheels will only require two to five step applications. **GlowGuide handrail works with the 6-step GLOWSTEP REVOLUTION® but must be installed on the second step from the bottom. |
|||||||||
| SMARTSTEP® GLOWSTEP REVOLUTION® Uprising Step System with 8" x 22.25" Steps | ||||||||
|---|---|---|---|---|---|---|---|---|
| Description / Part Number | Width between door frame flanges (A) | Height from ground to outside bottom corner of door threshold (B) | Step width distance in from door frame (C) | Bracket distance in from door frame (D) | Height from bottom of steps to top of All Terrain Landing Gear (E) | Overall Height (F) | Weight Capacity | Notes |
|
3-step Part Number: A9003 |
28" | 19-7/8" to 27-3/8" | 12-1/2" | 5" | 8-3/8" | 20-1/2" | 375 lbs | ††† |
|
4-step Part Number: A9004 |
28" | 27-3/8" to 34-7/8" | 12-1/2" | 5" | 10-1/2" | 22-1/2" | 375 lbs | ††† |
|
5-step Part Number: A9005 |
28" | 34-7/8" to-42 3/8" | 12-1/2" | 5" | 11-3/16" | 24-7/10" | 325 lbs | ††† |
|
6-step Part Number: A9006 |
28" | 42-3/8" to 49-7/8" | 12-1/2" | 5" | 11-3/16" | 26-4/5" | 300 lbs | ††† |
|
3-step Part Number: A9303 |
26" | 19-7/8" to 27-3/8" | 12-1/2" | 5" | 8-3/8" | 20-1/2" | 375 lbs | ††† |
|
4-step Part Number: A9304 |
26" | 27-3/8" to 34-7/8" | 12-1/2" | 5" | 10-1/2" | 22-1/2" | 375 lbs | ††† |
|
5-step Part Number: A9305 |
26" | 34-7/8" to 42-3/8" | 12-1/2" | 5" | 11-3/16" | 24-7/10" | 325 lbs | ††† |
|
6-step Part Number: A9306 |
26" | 42-3/8" to 49-7/8" | 12-1/2" | 5" | 11-3/16" | 26-4/5" | 300 lbs | ††† |
|
3-step Part Number: A9103 |
24" | 19-7/8" to 27-3/8" | 12-1/2" | 5" | 8-3/8" | 20-1/2" | 375 lbs | ††† |
|
4-step Part Number: A9104 |
24" | 27-3/8" to 34-7/8" | 12-1/2" | 5" | 10-1/2" | 22-1/2" | 375 lbs | ††† |
|
5-step Part Number: A9105 |
24" | 34-7/8" to 42-3/8" | 12-1/2" | 5" | 11-3/16" | 24-7/10" | 325 lbs | ††† |
|
6-step Part Number: A9106 |
24" | 42-3/8" to 49-7/8" | 12-1/2" | 5" | 11-3/16" | 26-4/5" | 300 lbs | ††† |
| 3-Step Part Number: A9403 | 30" | 19-7/8” To 27-3/8” | 12-½” | 5” | 8-3/8” | 20-½” | 375 Lbs | ††† |
| 4-Step Part Number: A9404 | 30” | 27-3/8” To 34-7/8” | 12-½” | 5” | 10-½” | 22-½ | 375 Lbs |
††† |
| 5-Step Part Number: A9405 | 30” | 34-7/8” To 42-3/8” | 12-½” | 5” | 11-3/16” |
24-7/10” |
325 Lbs |
††† |
| 6-Step Part Number: A9406 | 30" | 42-3/8” To 49-7/8” | 12-½” | 5" | 11-3/16” |
26-4/5” |
300 Lbs |
††† |
††† With use of Torklift GlowGuide. Otherwise, 3-4 step MAX CAP 350 lbs / 5-6 step MAX CAP 300 lbs
*The SMARTSTEP® GLOWSTEP REVOLUTION® Uprising is available from three to six steps.
