Installation Disclaimer: This blog is intended as a general reference only. It may not include every step, tool, torque specification, or vehicle-specific detail needed for your installation. Always refer to the official installation instructions included with your product for the complete procedure, required tools, torque values, safety information, and fitment details.
Installing Torklift T3310 tie downs on your Toyota Tacoma is a straightforward process that significantly enhances your truck's cargo-securing capabilities. This guide walks you through each step of the installation, helping you complete the job with confidence.
What You'll Need
Before starting your installation, gather the following items:
- Pry tool
- Socket wrench set
- Torque wrench
- Bolts with flat washers (included in kit)
- Half-inch bolts with plate washers (included in kit)
- Zip ties (supplied with tie downs)
Passenger Side Installation
Step 1: Remove the Frame Plugs
Begin by locating the plastic plugs at the rear of your vehicle's frame on the passenger side. Use a pry tool to carefully remove these plugs, exposing the mounting points underneath.
Step 2: Install the Lower Bolts
Take two bolts and place a flat washer on each one. Insert these bolts through the tie down bracket and into the frame. Secure them with the appropriate hardware included in your kit.
Step 3: Secure the Upper Mounting Point
Place a plate washer onto a half-inch bolt. Run this bolt through the bed support and the upper hole on the tie down bracket. Secure the upper bolt with the remaining hardware.
Step 4: Torque to Specification
Using a torque wrench, tighten all hardware to 90 ft-lb. This ensures your tie downs are securely mounted and ready for heavy-duty use.
Driver Side Installation
Step 1: Prepare the Wiring Harness
Before beginning the driver side installation, locate the plug harness and unclip it. Leave it hanging out of the way during the installation process.
Step 2: Repeat the Installation Process
The driver side installation follows the same procedure as the passenger side:
- Remove the plastic frame plugs with a pry tool
- Install two bolts with flat washers through the tie down and frame
- Secure with appropriate hardware
- Install the upper bolt with plate washer through the bed support
- Torque all hardware to 90 ft-lb
Step 3: Secure the Harness
Once the tie down is firmly secured to the truck, use the supplied zip ties to properly secure the driver side plug harness back into position.
Using Your Tie Downs
After installation is complete, your tie downs are ready for use. When you need to secure cargo, simply slide the insert into place and secure it with the provided pin. This quick-connect design makes it easy to add or remove tie down points as needed.
Important Reminders
Always refer to the official Torklift instructions when installing these products, as they are updated regularly with the latest specifications and procedures. This guide serves as a visual reference, but the manufacturer's instructions contain the complete and most current information.
Frequently Asked Questions
How tight should I torque the T3310 tie down bolts?
All hardware should be torqued to 90 ft-lb for proper installation.
Is the installation process different between the driver and passenger sides?
The process is the same on both sides, with one exception: on the driver side, you'll need to unclip and secure the wiring harness during installation.
What tools do I need for this installation?
You'll need a pry tool to remove the frame plugs, a socket wrench set for installation, and a torque wrench to properly tighten the hardware to specification.
How do I use the tie downs after installation?
Simply slide the insert into place and secure it with the provided pin. The system is designed for quick and easy attachment when you need it.
Where can I get help if I have questions during installation?
For any questions, visit the Torklift website or call 800-246-8132 for assistance.
Do I need to refer to additional instructions?
Yes, always refer to the official instructions included with your Torklift products, as they are updated regularly and contain complete installation details.
