Installation Disclaimer: This blog is intended as a general reference only. It may not include every step, tool, torque specification, or vehicle-specific detail needed for your installation. Always refer to the official installation instructions included with your product for the complete procedure, required tools, torque values, safety information, and fitment details.

Why Choose Torklift Frame-Mounted Tie Downs

The Torklift part number F3009 frame-mounted tie downs represent the strongest mounting option possible for a slide-in camper on your Ford truck. These tie downs bolt directly to your truck's frame, providing unmatched security and stability for your camper setup.

Built with quality and longevity in mind, these tie downs are proudly made in the USA and come with a lifetime warranty. The powder-coated finish ensures they're built to last through years of use and exposure to the elements.

What You'll Need

Before beginning your installation, gather the following components that come with your Torklift tie down kit:

  • Tie down receivers (left and right)
  • Bolt fisher (coiled tool for threading bolts through frame)
  • Plate washers
  • Internal tooth lock washers
  • Flat washers
  • Bolts and nuts
  • Bail pins
  • Tie down inserts

Step-by-Step Installation Process

Step 1: Remove Factory Hitch Bolts

Start by removing the two forwardmost bolts in the bottom of your trailer hitch. These factory bolt holes will be reused to secure the tie down receiver.

Step 2: Thread the Bolt Fisher

Insert the coiled end of the provided bolt fisher into the oval hole in the side of the frame, just above the trailer hitch. Guide the coiled end through the frame until it emerges from the back.

Step 3: Attach Hardware to the Fisher

Once the fisher exits the back of the frame, attach the following components in order:

  • Plate washer
  • Internal tooth lock washer
  • Bolt

Pull the assembly back through the frame, but don't pull it completely out of the hole yet.

Step 4: Position the Tie Down Receiver

Raise the tie down receiver into position, threading the fisher through its corresponding hole. This step requires careful alignment to ensure proper fitment.

Step 5: Reinstall Factory Bolts

Loosely reinstall the factory bolts you removed in Step 1. Keeping them loose at this stage allows for adjustment.

Step 6: Secure the New Hardware

Pull the bolt fisher to expose the connected bolt. Remove the fisher from the bolt. Secure the bolt with one flat washer, lock washer, and nut in that order.

Step 7: Torque All Hardware

Torque down all the hardware to ensure a secure, stable installation.

Step 8: Install the Second Receiver

Repeat this entire process to install the receiver on the other side of the vehicle.

Important Considerations

Wiring Harness Relocation

Depending on your year of vehicle, you may need to relocate a wiring harness in order to install the tie down. Check for any wiring that may interfere with the installation before beginning.

Using Your Torklift Tie Downs

When you're ready to use your Torklift tie downs, the process is simple:

  • Slide the insert into the receiver
  • Secure it with the provided bail pins

Your tie downs are now ready to secure your slide-in camper.

Installation Complete

Once both receivers are installed and all hardware is properly torqued, your installation is complete. Your Ford truck is now equipped with the strongest possible mounting system for your slide-in camper.

Need Help?

Always refer to the official Torklift instructions when installing these products, as they are updated regularly to reflect the most current installation procedures and specifications.

For any questions, you can:

Frequently Asked Questions

What makes frame-mounted tie downs stronger than other options?

Frame-mounted tie downs bolt directly to your truck's frame, creating the strongest mounting option possible for a slide-in camper.

Are Torklift tie downs covered by a warranty?

Yes, Torklift tie downs are backed by a lifetime warranty.

Where are these tie downs manufactured?

These tie downs are proudly made in the USA.

Do I need to remove my trailer hitch to install these tie downs?

No, you only need to remove the two forwardmost bolts in the bottom of the trailer hitch. The tie downs work in conjunction with your existing hitch.

Will these fit all years of Ford trucks?

The installation process is similar across models, but depending on your year of vehicle, you may need to relocate a wiring harness. Always check the official instructions for your specific vehicle.

What is a bolt fisher and why is it needed?

A bolt fisher is a coiled tool that allows you to thread bolts through the enclosed frame of your truck, making it possible to install hardware in areas that would otherwise be inaccessible.

How do I attach my camper once the receivers are installed?

Simply slide the insert into the receiver and secure it with the provided bail pins when you're ready to load your camper.
