The Torklift F3006 offers a clean, no-drill solution that integrates seamlessly with your factory trailer hitch. This guide walks you through the installation process so you can secure your truck camper with confidence.
What You'll Be Installing
The Torklift F3006 is designed specifically for 2011-2016 Ford Super Duty trucks. This system uses your existing factory trailer hitch cross tube, eliminating the need for drilling or permanent modifications to your vehicle.
Installation Steps
Step 1: Prepare the Tie Down Assembly
Begin by sliding the sleeve adapter over the crimped end of the tie down receiver. This adapter ensures a proper fit within your factory hitch tube.
Step 2: Insert Into Factory Cross Tube
Slide the complete assembly into the factory trailer hitch cross tube. The design allows the tie down receiver to fit securely without requiring any drilling.
Step 3: Install the Retainer Bracket
Once the assembly is positioned, install the retainer bracket onto the protruding threads. This bracket holds everything in place and provides the structural integrity needed for secure tie down points.
Step 4: Add Washers and Acorn Nut
Place the components onto the threads in this specific order:
- Bevel washer (with thin side facing the inside of the vehicle)
- Lock washer
- Acorn nut
The orientation of the bevel washer is critical for proper installation and performance.
Step 5: Tighten to Specification
Tighten the acorn nut until the lock washer is pressed completely flat. Once flat, continue tightening an additional 3/4 of a turn. This ensures proper tension and secure mounting.
Step 6: Repeat on Opposite Side
Complete the same installation process on the other side of your vehicle to create matching tie down points.
Step 7: Install Tie Down Inserts
When you're ready to use the system, install the tie down inserts into the receiver and secure them with the 1/4 inch pin provided.
Important Installation Notes
Adapter Sleeve Compatibility: Depending on your specific OEM tube size, the adapter sleeves may not be needed. Check your factory cross tube dimensions before installation.
Always Reference Official Instructions: Installation procedures are updated regularly. Always consult the instructions included with your Torklift product for the most current information and specifications.
Why Choose a No-Drill Solution
The Torklift F3006 system offers several advantages for Ford Super Duty owners:
- No permanent modifications to your truck
- Uses existing factory mounting points
- Maintains vehicle warranty integrity
- Clean, professional appearance
- Easy removal if needed
Need Additional Support?
If you have questions during installation or need clarification on any steps, Torklift provides direct support:
- Visit the Torklift website for resources and documentation
- Call 800-246-8132 to speak with a product specialist
Frequently Asked Questions
Do I need to drill any holes to install the F3006?
No. The F3006 is a no-drill system that uses your factory trailer hitch cross tube for installation.
Will I need the adapter sleeves for my truck?
It depends on your OEM tube size. The adapter sleeves may not be needed for all applications.
How tight should I make the acorn nut?
Tighten until the lock washer is pressed flat, then continue for an additional 3/4 of a turn.
Which direction should the bevel washer face?
The thin side of the bevel washer should face the inside of the vehicle.
Do I need to install tie downs on both sides?
Yes, repeat the installation process on the opposite side of the vehicle for balanced tie down points.
What size pin secures the tie down inserts?
Use the 1/4 inch pin provided with your kit to secure the tie down inserts into the receiver.
Where can I find the most current installation instructions?
Always refer to the instructions included with your Torklift product, as they are updated regularly. You can also contact Torklift at 800-246-8132 or visit their website for support.
