Installation Disclaimer: This blog is intended as a general reference only. It may not include every step, tool, torque specification, or vehicle-specific detail needed for your installation. Always refer to the official installation instructions included with your product for the complete procedure, required tools, torque values, safety information, and fitment details.
Installing Torklift tie downs on your Dodge or Ram truck provides secure anchor points for hauling cargo and securing loads. This guide walks you through the installation process for the D2127 tie down system, demonstrated on a 2018 Dodge 3500.
Pre-Installation Preparation
Before you begin the installation process, take these important safety steps:
- Disengage the parking brake
- Chalk the wheels to prevent vehicle movement
These precautions ensure your safety throughout the installation process and prevent the vehicle from rolling.
Understanding the Installation Process
The installation instructions are identical for both the driver and passenger sides of your vehicle. You can start with either side, though this guide follows the passenger side installation first.
Step-by-Step Installation Instructions
Installing the Center Mounting Bolt
Begin by preparing your center mounting bolt assembly. Take a grade 8 bolt and add a star washer and plate washer onto a bolt fisher. This bolt fisher tool will help you navigate the bolt through tight spaces within your truck's frame.
Fish the bolt through the center mounting point as indicated in your instruction booklet. This requires careful maneuvering to ensure proper alignment.
Positioning the Tie Down Receiver
Slide the top flange on the tie down receiver between the parking brake cable and frame. This positioning is critical for proper installation and function.
Pull the bolt fisher assembly through the frame and through the tie down receiver center mounting point. Once the bolt is properly positioned, carefully remove the bolt fisher.
Complete the center bolt assembly by placing a flat washer, lock washer, and grade 8 hex nut onto the bolt.
Installing the Side Bolts
Insert two 4.5 inch grade 8 hex bolts with flat washers through the tie down receiver and backing plate. These bolts provide the primary structural support for your tie down system.
Adding Tubing Spacers (Ram 3500 Only)
If you're installing on a Ram 3500 truck, slide one tubing spacer onto each of the 4.5 inch grade 8 bolts. Position these spacers between the backing plate and the tie down receiver.
Important: Tubing spacers are only required on Ram 3500 trucks. Other models do not need these spacers.
Securing the Assembly
Secure each bolt assembly with a flat washer, lock washer, and grade 8 hex nut. Hand tighten all fasteners initially before final torquing.
Refer to your instruction booklet for the recommended torque ratings. Proper torque is essential for safe and secure installation.
Completing the Installation
Once you've finished the passenger side, repeat all instructions for the driver's side of the vehicle. The process is identical for both sides.
After both sides are installed and properly torqued, your installation is complete.
Hardware Components Summary
Your installation uses the following grade 8 hardware:
- Grade 8 bolts (center mounting)
- Grade 8 hex bolts, 4.5 inches (side mounting)
- Star washers
- Plate washers
- Flat washers
- Lock washers
- Grade 8 hex nuts
- Tubing spacers (Ram 3500 only)
Important Reminders
Always refer to the official Torklift instructions when installing these products. Instructions are updated regularly to reflect the latest installation procedures and specifications.
The torque ratings specified in your instruction booklet must be followed precisely to ensure safe and proper installation.
Frequently Asked Questions
Q: Are the installation steps the same for both sides of the truck?
A: Yes, the installation instructions are identical for both the driver and passenger sides of the vehicle.
Q: Do I need tubing spacers for my truck?
A: Tubing spacers are only required on Ram 3500 trucks. They are not needed for other models.
Q: What should I do before starting the installation?
A: Disengage the parking brake and chalk the wheels before beginning the installation.
Q: Where can I find the torque specifications?
A: Refer to your instruction booklet for the recommended torque ratings for all fasteners.
Q: Which side should I start with?
A: You can start with either the driver or passenger side. The installation process is the same for both sides.
Q: Where can I get help if I have questions during installation?
A: Visit the Torklift website or call 800-246-8132 for assistance with any installation questions.
Q: Why should I refer to the official instructions?
A: Torklift instructions are updated regularly to ensure you have the most current installation procedures and specifications for your specific application.
