Installation Disclaimer: This blog is intended as a general reference only. It may not include every step, tool, torque specification, or vehicle-specific detail needed for your installation. Always refer to the official installation instructions included with your product for the complete procedure, required tools, torque values, safety information, and fitment details.
Installing Torklift frame-mounted tie downs on your Ford Ranger provides secure anchor points for hauling cargo, securing equipment, or towing. The F2026 and F2027 models are specifically designed for 2019-2025 Ford Ranger trucks, and with the right approach, you can complete this installation yourself.
This guide walks you through the complete installation process, from threading bolt fishers through your truck's frame to securing both tie down receivers in place.
What You'll Need
Before starting your installation, gather the following components that come with your Torklift tie down kit:
- Half-inch bolt fishers (coiled wire tools)
- Half-inch bolts
- Star washers
- Plate washers
- Nuts
- Tie down receivers
- Bail pins (for securing inserts)
Installing the First Side
Step 1: Thread the First Bolt Fisher
Start by locating the oval hole toward the front end of your truck's frame. Insert the coiled end of a half-inch bolt fisher through the bottom of the frame and guide it out through this oval hole.
Step 2: Attach Hardware to the Bolt Fisher
Once the coiled end emerges from the oval hole, prepare your first bolt:
- Slide a star washer onto a half-inch bolt
- Add a plate washer on top of the star washer
- Thread this assembly onto the coiled end of the bolt fisher
Step 3: Pull Hardware Through the Frame
Insert the hardware one piece at a time back through the frame. Pull on the straight end of the bolt fisher until the bolt shows through the frame opening. Keep the bolt fisher attached for now.
Step 4: Repeat for Remaining Mounting Points
Repeat this entire process two more times:
- Second bolt: Thread through the hole located up and backward from the first hole
- Third bolt: Thread through the oval hole slightly toward the front of the truck on the frame
You should now have three bolts with fishers attached, all protruding through the appropriate frame holes.
Step 5: Mount the Tie Down Receiver
With all three bolts and fishers in place, feed the bolts through the corresponding holes on the tie down receiver. This positions your tie down on the truck frame.
Step 6: Secure the Hardware
Remove the bolt fishers from each bolt. Then install the remaining washers and nuts onto each bolt, securing the tie down receiver to the frame.
Step 7: Torque to Specification
With all hardware fastened, torque the bolts to the foot-pounds specified in your installation instructions. Proper torque is critical for safe operation.
Installing the Second Side
The installation process for the opposite side of your truck is nearly identical to the first side, with one minor difference.
The only variation occurs when threading the coiled end of the bolt fisher for the rearward-most hole. The specific threading location differs slightly from the first side due to frame geometry.
Follow the same seven-step process outlined above, paying attention to this variation for the rear mounting point.
Using Your Torklift Tie Downs
Once both receivers are installed and secure, your tie downs are ready for use.
To deploy a tie down:
- Slide the insert into the receiver at your desired length
- Secure it in place with the provided bail pin
The adjustable insert design allows you to position the tie down point exactly where you need it for different cargo and hauling situations.
Important Reminders
This guide provides a visual reference for the installation process. Always refer to the official Torklift instructions when installing these products, as they are updated regularly with the latest specifications and procedures.
The written instructions included with your tie downs contain specific torque values, detailed diagrams, and any vehicle-specific notes that may apply to your particular Ford Ranger model year.
Frequently Asked Questions
What Ford Ranger models are compatible with the F2026 and F2027 tie downs?
These tie downs are designed for 2019-2025 Ford Ranger trucks.
How many mounting points does each tie down use?
Each tie down receiver mounts using three bolts through existing frame holes.
What is a bolt fisher and why is it used?
A bolt fisher is a coiled wire tool that helps thread bolts through enclosed frame sections where you cannot reach both ends simultaneously. It allows you to guide hardware through the frame from one access point.
Are the installation steps the same for both sides of the truck?
The process is mostly identical for both sides. The only difference is where the coiled end of the bolt fisher is threaded for the rearward-most hole on the second side.
Do I need to drill any holes in my truck frame?
No. The installation uses existing frame holes in your Ford Ranger.
Where can I find the specific torque specifications?
Torque specifications are provided in the installation instructions included with your Torklift tie down kit. Always refer to these official instructions for exact foot-pound values.
Can I adjust the tie down position after installation?
The receivers are fixed once installed, but the insert slides to different lengths within the receiver and locks in place with a bail pin, giving you adjustable tie down points.
Where can I get help if I have questions during installation?
Contact Torklift directly at 800-246-8132 or visit their website for installation support.
