SuperHitch® Magnum 30K-F1003-30
IN STOCK
The SuperHitch® Magnum 30K is the heaviest-duty hitch and extension system ever. Built for truck campers with rear overhang, its dual-receiver design is the required foundation for a SuperTruss extension so you can tow a trailer behind your camper with a strong, stable connection. Made in the USA and backed by a Legendary Lifetime Warranty.
Key Specifications (F1003-30)
• Fits 2005-2015 Ford Super Duty F350/F450/F550 34" frame, 2016 Ford Super Duty F550 34" frame
• Dual receivers: 2.5″ upper / 2″ lower
• 30,000 lb pull / 3,000 lb tongue (weight distribution)
• 20,000 lb pull / 2,500 lb tongue (weight carrying)
• No drilling required for 2005-2015 Ford Super Duty F350/F450/F550 34" frame, 2016 Ford Super Duty F550 34" frame
• Made in USA | Legendary Lifetime Warranty
This kit ships complete. Kit includes bolt/accessory kits
- SKU
- F1003-30
Shipping Info
All Torklift products ship in 5 business days or less.
If you order multiple products, they may ship from different warehouses in separate shipments
7 Essentials for Safe Camper Hauling
Walk through the key parts of a safe truck camper setup, then mark what you already have and what you still need.
Your Safe Hauling Checklist
You are complete. Review what is done, what is still needed, and continue from your saved spot.
You reviewed all 7 essentials.
Here are the products you marked as needed.
Nice work - you marked every item!
SuperHitch® Magnum 30k Features
-
SuperHitch® 30K frame mounted receiver rated up to 30,000 lbs pull and 3,000 lbs tongue weight with weight distribution (20,000 lbs pull and 2,500 lbs tongue weight carrying) in either the upper or lower receivers when used without a SuperTruss extension
-
SuperTruss extensions available in 8 lengths from 21" to 60" (sold separately)
-
Upper receiver is 2.5" (accepts 2.5" ball mounts; use a 2.5" to 2" reducer sleeve if using a 2" shank in the upper); lower receiver is 2" (accepts 2" ball mounts and SuperTruss extensions)
-
Eliminates the need for two ball mounts by allowing ball height variance using either the upper or lower SuperHitch® receiver
-
Specific Torklift tie down fits are available for the SuperHitch® Outlaw Series
-
Legendary Lifetime Warranty
-
Proudly made in the USA
Fitment
Please Note: Upgrading your Factory/OEM hitch to a SuperHitch will change your rear tie down application. Torklift rear tie down part number R3504 is the compatible rear tie down with this SuperHitch.
|
Year |
Vehicle |
Fitment |
|
2005 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2006 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2007 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2008 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2009 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2010 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2011 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2012 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2013 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2014 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2015 |
Ford Super Duty F350/F450/F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
|
2016 |
Ford Super Duty F550 |
All cabs, 4x2 or 4x4, Gas or Diesel, 34" Frame |
Receiver & Ball Mount Compatibility
-
Upper receiver: 2.5" opening. Use 2.5" ball mounts/drawbars; if using a 2" accessory in the upper receiver, a 2.5" to 2" reducer sleeve is required (reducer sleeve included in kit).
-
Lower receiver: 2" opening. Accepts 2" ball mounts and the SuperTruss extension.
-
SuperTruss extensions easily installs into dual receiver and accept 2" accessories.
Installation At A Glance
-
No drilling required on 2005-2015 Ford Super Duty F350/F450/F550 34" frame, 2016 Ford Super Duty F550 34" frame applications.
-
Estimated install time: 1.5–2.5 hours with standard shop tools.
-
Tools commonly used: torque wrench, sockets, box wrenches, safety glasses.
-
Torque: Tighten all fasteners to the values specified in the installation instructions for F1003-30; re-torque after initial use.
-
Camper tie-down note: Upgrading your Factory/OEM hitch to a SuperHitch will change your rear tie down application. Torklift rear tie down part number R3504 is the compatible rear tie down with this SuperHitch.
What’s Included
-
1 x SuperHitch® Magnum 30K receiver assembly (F1003-30)
-
1 x Reducer Sleeve (M9006)
-
1 x Complete bolt and accessory hardware kit (included)
-
2 x Hitch pin/clips for hitch pin locations with reinforced pin holes
-
1 x Installation instruction set for F1003-30
Accessories required to achieve listed ratings:
-
Weight distribution system required to reach 30,000 lb pull / 3,000 lb tongue (no extension) and 12,000 lb pull / 1,200 lb tongue when using a 48" SuperTruss
-
SuperTruss extension (sold separately) required when towing with a truck camper or bed overhang
Capacity Matrix (F1003-30 SuperHitch Magnum 30K with SuperTruss Extension)
Capacities shown are when SuperHitch is used with SuperTruss extension.
|
Capacities (Weight Carrying) |
Capacities (Weight Distributing) |
|
|
Length |
Tongue Weight / Pull Weight (lbs) |
Tongue Weight / Pull Weight (lbs) |
|
21" |
750 / 7,500 |
1,400 / 14,000 |
|
24" |
750 / 7,500 |
1,400 / 14,000 |
|
28" |
750 / 7,500 |
1,200 / 12,000 |
|
32" |
650 / 6,500 |
1,200 / 12,000 |
|
36" |
650 / 6,500 |
1,200 / 12,000 |
|
42" |
600 / 6,000 |
1,200 / 12,000 |
|
48" |
600 / 6,000 |
1,200 / 12,000 |
|
60" |
500 / 5,000 |
1,000 / 10,000 |
Note: SuperTruss extensions are offered up to 60". See the SuperTruss extension guide for detailed ratings by length and configuration.
What is a SuperHitch?
SuperHitch is Torklift’s frame mounted receiver hitch line featuring our patented dual receiver design for strength and towing versatility. Featuring the highest weight ratings in the world, the SuperHitch and SuperTruss extension system is specifically designed for truck camper owners that tow heavy behind their truck camper set up.
Are SuperHitch hitches vehicle specific?
Yes. Each SuperHitch part number is engineered for a specific application, so fitment depends on the vehicle.
How do I confirm the towing rating for my hitch?
Use the rating shown for your exact SuperHitch part number (or SuperTruss extension if being used in conjunction with your SuperHitch) and stay within the lowest rated component in the system, including the vehicle, hitch, ball mount, and accessories.
What is the difference between weight carrying and weight distribution ratings?
Weight carrying is towing without adding a weight distribution system. Weight distribution is towing with a properly set up weight distribution system. Ratings can differ by configuration.
What receiver sizes are used on SuperHitch hitches?
SuperHitch Hero 15K and SuperHitch Original 20K hitches have two 2” receivers. SuperHitch Magnum 30K has a 2.5” receiver at the top and 2” receiver at the bottom.
Does installation require drilling?
SuperHitch applications confirmed after 2001 are 100% no drill applications.
What is included with a SuperHitch kit?
Kits ship complete with the hitch assembly and the required installation hardware. Contents vary by part number.
Can I use an extension with a SuperHitch?
Yes. Use the SuperTruss extension to tow behind your truck camper set up. See SuperTruss Guide here.
How do I know I am buying a genuine SuperHitch?
The best way to ensure you are purchasing a genuine SuperHitch is to buy through Torklift or an authorized dealer and verify you are receiving the correct Torklift SuperHitch part number for your application.
Why does buying from the manufacturer matter?
Buying directly from the manufacturer helps ensure you get correct part number selection, current product specifications, and access to installation instructions, support, and warranty coverage.
What support does Torklift provide after purchase?
We provide product information, installation guidance resources, and warranty support for SuperHitch products.
Are replacement hardware and install components available?
Yes. If you need replacement hardware for your SuperHitch, contact Torklift support by email or at 800.246.8132 with your part number so we can help identify the correct components.
How can I confirm the correct SuperHitch part number for my vehicle?
Use the fitment guidance on Torklift.com or contact Torklift support. Confirming the correct part number ensures proper fit and that you are referencing the correct published ratings.
Are product specifications on Torklift.com the official specifications?
Yes. Specifications listed on Torklift.com are the manufacturer specifications for the products we sell.
Where are SuperHitch hitches made?
SuperHitch hitches are proudly designed, engineered, and manufactured in the USA.
What warranty is included with SuperHitch?
SuperHitch hitches are backed by the Torklift Legendary Lifetime Warranty
